Main parameters:
|
Printing Material’s way |
Left to right |
|
Mechanical Speed |
580m/min |
|
Max Laminating Speed |
500m/min |
|
(The maximum production speed will be affected by the quality and properties of the substrate and binder used) |
|
|
Max coating width |
1050mm/1350mm |
|
Max roll width |
1050mm/1350mm |
|
Min roll width |
400mm |
|
Unwind paper core |
3’’=76mm and 6’’=152mm |
|
Rewind paper core |
3’’=76mm and 6’’=152mm |
|
Unwind tension range |
3--40kg(400N) |
|
Rewind tension range |
4--55kg(550N) |
|
Rewind tape tension setting range |
100%--60% |
|
Max roll weight |
1,000kg |
|
Coating range |
0.8-3g/㎡ |
|
Dimension |
5100x3600x2500MM |
|
Power |
53KW |
|
Weight |
14000KG/16000kgs |
|
Machine color |
Ivory white |
